The Sonitus Legato 8 Acoustical Absorber is an 8cm deep (3.15 in) absorber made of high-performance polyester acoustic foam with a smooth stylized velour finish layer. Unlike fiberglass-filled absorber panels, or other fillers made from lower quality foams, the Legato 8's curved surface naturally blends into your walls for a clean look and does not shed, crumb, dissolve, or itch. Due to its unique design, the Legato 8's highly effective surface area absorbs a wide range of frequencies from 270Hz up to 20kHz. When combined with the appropriate Sonitus diffusers and bass trap(s), the Sonitus Legato 8 Acoustical Absorber is an excellent and elegant solution for balancing the frequencies of room acoustics and sound reflection control. *Sold in package of 6. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 270Hz to 20kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 3.25” (60cm x60cm x 8cm)
Colors: Black, White, Red, Blue, Gray
Coverage Area: 3.9 sq. ft.
Weight: 1.5 lbs.
Master Pack: 6 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
The Sonitus Legato 12 Acoustical Absorber is a 12cm deep (4.72 in) absorber made of high-performance polyester acoustic foam with a smooth stylized velour finish layer. Unlike fiberglass-filled absorber panels, or other fillers made from lower quality foams, the Legato 12's curved surface naturally blends into your walls for a clean look and does not shed, crumb, dissolve, or itch. Due to its unique design, the Legato 12's highly effective surface area absorbs a wide range of frequencies from 160Hz up to 20kHz. When combined with the appropriate Sonitus diffusers and bass trap(s), the Sonitus Legato 12 Acoustical Absorber is an excellent and elegant solution for balancing the frequencies of room acoustics and sound reflection control. *Sold only in package of 4. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 160Hz to 20kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 4.7” (60cm x60cm x 12cm)
Colors: Black, White, Red, Blue, Gray
Coverage Area: 3.9 sq. ft.
Weight: 2 lbs.
Master Pack: 4 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
The Sonitus Legato 12 Melamine Acoustical Absorber is a 12cm deep (4.72 in) absorber made of high-performance Melamine acoustic foam with a smooth stylized velour finish layer. Melamine has a unique structure that is particularly effective acoustically. Unlike fiberglass-filled absorber panels or other fillers made from lower quality foams, the Legato 12 Melamine’s curved surface naturally blends into your walls for a clean look and does not shed, crumb, dissolve, or itch. Due to its unique design and materials, the Legato 12 Melamine’s highly effective surface area absorbs a wide range of frequencies from 160Hz up to 20kHz. When combined with the appropriate Sonitus diffusers and bass trap(s), the Sonitus Legato 12 Melamine Acoustical Absorber is an excellent and elegant solution for balancing the frequencies of room acoustics room balancing and sound reflection control. *Sold in package of 4. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 160Hz to 20kHz
Material: USAP - Unique Sonitus Acoustic Melamine foam - fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 4.7” (60cm x60cm x 12cm)
Colors: White
Coverage Area: 3.9 sq. ft.
Weight: 2 lbs.
Master Pack: 4 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
The Sonitus Canvas panel absorber is a 6cm deep (2.36 in) absorber made of high-performance polyester acoustic foam wrapped with a smooth fabric outer layer. They are easy to install and it’s easy to know how many are needed by following the recommendations in the “How Many” tab located to the left. The Sonitus Canvas panel absorbers are also a highly effective solution when used overhead as “clouds” for soaking up nasty first reflections from ceilings. Construction details feature solid wood high-quality internal framing with cross support bracing at the center so the fabric wrapping won’t sag when hung overhead. The Sonitus Canvas panel absorbers cover a wide range of frequencies from 400Hz to 20kHz. *Sold in package of 2. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 400Hz to 20kHz (as cloud with 1” air gap)
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min with fabric cover.
Size: 23.6” x 47.3” x 2.6” (60cm x60cm x 6cm)
Colors: Black, White
Coverage Area:7.8 sq. ft.
Weight:11 lbs.
Master Pack: 2 Units
Mounting: Built-in Clips or separate hanging eyebolts
• 100-200 sq. ft. = 5 Units
• 201-300 sq. ft. = 6 Units
• 301-400 sq. ft. = 8 Units
• 401-500 sq. ft. = 10 Units
• 501-600 sq. ft. = 11 Units
• 601-700 sq. ft. = 12 Units
The Sonitus Quadsorber 6 is a 6cm deep (2.36 in) absorber made of high-performance polyester acoustic foam sculpted in a series of strategic channel shapes designed to capture a specific range of sound waves. Quadsorbers can be used as single units, in a multi-absorber room array, or in grouped patterns for vocal or isolation booths. The Quadsorber 6 has a modern industrial look and effectively absorbs from 500Hz to 20kHz. Lightweight and easy to install with spray glue, construction adhesives, or the optional magnetic installation kit. *Sold in package of 10. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 500Hz to 20kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 2.4” (60cm x60cm x 6cm)
Color: Charcoal Gray
Coverage Area: 3.9 sq. ft.
Weight: 1 lb.
Master Pack: 10 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
• 100-200 sq. ft. = 12 Units
• 201-300 sq. ft. = 14 Units
• 301-400 sq. ft. = 20 Units
• 401-500 sq. ft. = 24 Units
• 501-600 sq. ft. = 28 Units
• 601-700 sq. ft. = 30 Units
This is a special order item. Please contact us.
The Sonitus Quadsorber 8 is an 8cm deep (3.15 in) absorber made of high-performance polyester acoustic foam sculpted in a series of strategic channel shapes designed to capture a specific range of sound waves. Quadsorbers can be used as single units, in a multi-absorber room array, or in grouped patterns for vocal or isolation booths. The Quadsorber 8 has a modern industrial look and effectively absorbs from 315Hz to 20kHz. Lightweight and easy to install with spray glue, construction adhesives, or the optional magnetic installation kit. *Sold in package of 8. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 315Hz to 20kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 3.25” (60cm x60cm x 8cm)
Color: Charcoal Gray
Coverage Area:3.9 sq. ft.
Weight:1 lb.
Master Pack: 8 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 16 Units
• 401-500 sq. ft. = 20 Units
• 501-600 sq. ft. = 22 Units
• 601-700 sq. ft. = 24 Units
The Sonitus Decosorber Eva is a decorative mid-frequency damped-membrane absorber that is stylish and compensates for the common effects of excessive high-frequency damping. The Decosorber Eva absorbs from 200Hz to 3kHz and can be mounted as single units on walls or ceilings and/or together in desired groupings. Each unit is constructed with a core of 8cm USAP Polyester foam finished with black velvet and covered with a 4mm poplar plywood plate available in different semi-gloss wood tones to offer a wide variety of aesthetic options. *Sold in package of 6. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 200Hz to 3kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 3.125” (60cm x60cm x 8cm)
Coverage Area: 3.9 sq. ft.
Weight: 3 lbs.
Master Pack: 6 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: Walnut, Poplar (light maple)
Special Order Colors: Walnut, Natural Poplar, Black
The Sonitus Decosorber Maze is a decorative mid-frequency damped-membrane absorber that is stylish and compensates for the common effects of excessive high-frequency damping. The Decosorber Maze absorbs from 200Hz to 3kHz and can be mounted as single units on walls or ceilings and/or together in desired groupings. Each unit is constructed with a core of 8cm USAP Polyester foam finished with black velvet and covered with a 4mm poplar plywood plate available in different semi-gloss wood tones to offer a wide variety of aesthetic options. *Sold in package of 6. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 200Hz to 3kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 3.125” (60cm x60cm x 8cm)
Coverage Area: 3.9 sq. ft.
Weight: 3 lbs.
Master Pack: 6 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: Walnut, Poplar (light maple)
Special OrderColors: Walnut, Natural Poplar, Black
The Sonitus Decosorber Quad 8 is a decorative mid-frequency damped-membrane absorber and compensate for the common effects of excessive high-frequency damping. The Decosorber Quad 8absorbs from 200Hz to 3kHz and can be mounted as single units on walls or ceilings and/or together in desired groupings. Each unit is constructed with core of 8cm USAP Polyester foam finished with black velvet and covered with a 4mm poplar plywood plate available in different semi-gloss wood tones to offer a wide variety of aesthetic options. *Sold in package of 6. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 200Hz to 3kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 3.125” (60cm x60cm x 8cm)
Coverage Area: 3.9 sq. ft.
Weight: 3 lbs.
Master Pack: 6 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: Walnut, Black, and Poplar(light maple)
Special Order Colors: Mahogany, White, Wine Red
The smallest sized absorber in the Sonitus Decosorber line, the Mini Eva is a decorative mid-frequency damped membrane absorber that is stylish and compensates for the common effects of excessive high-frequency absorption. The Mini Eva Decosorber’s surface design pattern is comprised of unique slits that mimic stretched parallelograms which provide a full 40% of the front surface area for soundwave absorption. The Mini Eva Decosorber absorbs frequencies from 200Hz to 3kHz and can be mounted as single units on walls or ceilings and/or together in desired groupings. Each unit is constructed with a back layer of 8cm (3.15in) USAP Polyester foam finished with black velvet and covered with a 4mm poplar plywood plate available in different semi-gloss wood tones to offer a wide variety of aesthetic options. *Sold in package of 12. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Test ReportFrequency Range: 200Hz to 3kHz
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 11.8” x 3.125” (60cm x60cm x 8cm)
Coverage Area: 1.9 sq. ft.
Weight: 1.5 lbs.
Master Pack: 12 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: Walnut, Poplar (light maple), WineRed
Special OrderColors: Mahogany
• 100-200 sq. ft. = 23 Units
• 201-300 sq. ft. = 28 Units
• 301-400 sq. ft. = 40 Units
• 401-500 sq. ft. = 48 Units
• 501-600 sq. ft. = 56 Units
• 601-700 sq. ft. = 60 Units
The Sonitus Bigfuser II Solid Oak Acoustical Diffuser is a showstopper. Weighing in at 49 lbs and with a 16cm depth (6.25 in), this solid-oak 3D diffuser is a series of block and cavity shapes for effective broadband hemispherical scattering. The fascia is curved for easier integration to existing room décor. This unique shape converts incoming sound waves into a 3-dimensional space for a more enveloping soundfield. Bigfuser II Solid Oak eliminates slap echoes while maintaining mid and high-frequency energy in the room. Sonitus Bigfusers scatter a wide range of frequencies from 350Hz to 6kHz. They are part of a balanced treatment approach when used with 2D diffusers, absorbers, and Decosorbers in a total room acoustic plan. Four keyhole mounts on the backplane of the module make for an easy integrated installation by using properly rated wall fasteners. *Sold in single units. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 350Hz to 6kHz
Material: Solid Oak
Size: 23.6” x 23.6” x 6.25” (60cm x60cm x 16cm)
Colors: Oak, Black, White, Mahogany
Coverage Area: 3.9 sq. ft.
Weight: 49 lb.
Master Pack: 1 Unit
Mounting: 4 Keyholes for mounting screws
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 14 Units
• 401-500 sq. ft. = 16 Units
• 501-600 sq. ft. = 18 Units
• 601-700 sq. ft. = 22 Units
The Sonitus Bigfuser II is a 16cm deep (6.25 in) 3D diffuser made of hardened expanded polystyrene with an acrylic paint finish sculpted in a series of randomized block and cavity shapes for effective hemispherical scattering. The unique shape converts incoming sound waves into a 3-dimensional space for a more enveloping sound field. This affordable design eliminates slap echoes while maintaining mid and high-frequency energy in the room. Bigfusers scatter a wide range of frequencies from 375Hz to 6kHz. They are part of a balanced treatment approach when used with 2D diffusers, absorbers, and Decosorbers in a total room acoustic plan. Easy installation with spray glue, construction adhesives, or the optional magnetic installation kit. *Sold in package of 3. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 375Hz to 6kHz
Material: Hard expanded polystyrene with acrylic paint finish
Size: 23.6” x 23.6” x 6.25” (60cm x60cm x 16cm)
Colors: Black
Coverage Area: 3.9 sq. ft.
Weight: 2 lb.
Master Pack: 3 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Special Order Colors: Gray, White
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 14 Units
• 401-500 sq. ft. = 16 Units
• 501-600 sq. ft. = 18 Units
• 601-700 sq. ft. = 22 Units
The Sonitus Bigfuser II is a 16cm deep (6.25 in) 3D diffuser made of hardened expanded polystyrene with an acrylic paint finish sculpted in a series of block and cavity shapes for effective hemispherical scattering. The fascia is curved for easier integration to existing room décor. The unique shape converts incoming sound waves into a 3-dimensional space for a more enveloping soundfield. This affordable design eliminates slap echoes while maintaining mid and high-frequency energy in the room. Bigfusers scatter a wide range of frequencies from 375Hz to 6kHz. They are part of a balanced treatment approach when used with 2D diffusers, absorbers, and Decosorbers in a total room acoustic plan. Easy installation with spray glue, construction adhesives, or the optional magnetic installation kit. *Sold in package of 3. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 375Hz to 6kHz
Material: Hard expanded polystyrene with acrylic paint finish
Size: 23.6” x 23.6” x 6.25” (60cm x60cm x 16cm)
Colors: Black, White
Coverage Area: 3.9 sq. ft.
Weight: 2 lb.
Master Pack: 3 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Special Order Colors: Gray
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 14 Units
• 401-500 sq. ft. = 16 Units
• 501-600 sq. ft. = 18 Units
• 601-700 sq. ft. = 22 Units
The Sonitus 6-Strip All-In-One 7cm deep (2.76 in) module is a combination 2D slat diffuser and dense foam absorber all in one single device. It combines two separate actions in one, converting incoming sound waves into a 2-dimensional plane for a more enveloping sound-field. The 6-Strip module eliminates slap echoes while maintaining mid and high-frequency energy in the room, scatters a range of frequencies from 1kHz to 6kHz, and further absorbs frequencies from 250Hz to 3kHz. The Sonitus 6-Strip All-In-One is part of a balanced treatment approach when used with 3D diffusers, absorbers, and Decotraps in a total room acoustic plan. Easy installation with the integrated clips and wall brackets. *Sold in package of 2. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities..
Frequency Range: 2D Scattering from 1kHz to 6kHz, and Absorption from 250Hz to 3kHz
Material: Solid woodenclosure and slats with USAP – Polyester acoustic foam - fire resistantFMVSS 302<100mm/min
Size: 23.6” x 23.6” x 2.75” (60cm x60cm x 7cm)
Colors: Oak
Coverage Area: 3.9 sq. ft.
Weight: 8.5 lb.
Master Pack: 2 Units
Mounting: Integrated clips and wall cleatbrackets.
Special Order Color: Mahogany
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 14 Units
• 401-500 sq. ft. = 16 Units
• 501-600 sq. ft. = 18 Units
• 601-700 sq. ft. = 22 Units
The Dimension 4 DR6 is a 60cm x 60cm x 15cm (24 x 24 x 6 in) 3-dimensional scattering module made of lightweight synthetic material. It scatters sound energy in a randomized hemispherical sound field and is recommended for use on side walls towards the back of the room, on back walls, and, on the ceiling towards the back of the room behind the seating position. The Dimension 4 DR6 provides a very enveloping sound field which is needed for 2-channel and immersive multi-channel sound, is easy to install, and has a modern industrial aesthetic. *Sold in package of 1. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
The Sonitus Fourfuser is an 8cm (3.15 in) deep 2D sound scattering module made of hardened expanded polystyrene with acrylic paint finish sculpted in a series of ridge and channel shapes for an effective planar diffusion pattern. The unique shape converts incoming sound waves into a 2-dimensional plane for a more enveloping sound-field. This very affordable module eliminates slap echoes while maintaining mid and high-frequency energy in the room. Fourfuser scatters a wide range of frequencies from 600Hz to 4kHz. They are part of a balanced treatment approach when used with 3D diffusers, absorbers, and Decosorbers in a total room acoustic plan. Easy installation with spray glue, construction adhesives, or the optional magnetic installation kit. *Sold in package of 6. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 600Hz to 4kHz
Material: Hard expanded polystyrene with acrylic paint finish
Size: 23.6” x 23.6” x 3.25” (60cm x60cm x 8cm)
Colors: Black, Gray, White
Coverage Area: 3.9 sq. ft.
Weight: 1 lb.
Master Pack: 6 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Special Order Colors: White
• 100-200 sq. ft. = 10 Units
• 201-300 sq. ft. = 12 Units
• 301-400 sq. ft. = 14 Units
• 401-500 sq. ft. = 16 Units
• 501-600 sq. ft. = 18 Units
• 601-700 sq. ft. = 22 Units
The Sonitus Decotrap Maze low-frequency absorber is a decorative damped membrane absorber that fits well with existing room aesthetics and operates in the critical standing wave frequency spectrum. When corner-mounted, Decotrap takes over where a mid/high frequency absorber’s range typically slopes off and treats frequencies from 60Hz to 500Hz. It features a core of 25cm USAP Polyester foam finished with black velvet then covered with a 4mm poplar plywood plate that is available in different wood colors with a semi-gloss finish. Decotraps can be used as single or multiple units in front and back corners of your room depending on the level of room bass management needed to best balance your space. See the ‘How Many?’ tab for quantity suggestions. *Sold in package of of 2. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 60 to 500Hz with corner placement
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 9.7” (60cm x60cm x 25cm)
Coverage Area: 3.9 sq. ft.
Weight: 6 lbs.
Master Pack: 2 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: Walnut, Natural Poplar, Black
Special Order Colors: Mahogany
• 100-200 sq. ft. = 2 Units
• 201-300 sq. ft. = 4 Units
• 301-400 sq. ft. = 6 Units
• 401-500 sq. ft. = 8 Units
• 501-600 sq. ft. = 12 Units
• 601-700 sq. ft. = 16 Units
The Sonitus Decotrap Quad low-frequency absorber is a decorative damped membrane absorber that fits well with existing room aesthetics operates in the critical standing wave frequency spectrum. When corner-mounted, Decotrap takes over where a mid/high frequency absorber’s range typically slopes off and treats frequencies from 60Hz to 500Hz. It features a core of 25cm USAP Polyester foam finished with black velvet then covered with a 4mm poplar plywood plate that is available in different wood colors with a semi-gloss finish. Decotraps can be used as single or multiple units in front and back corners of your room depending on the level of room bass management needed to best balance your space. See the ‘How Many?’ tab for quantity suggestions. *Sold in package of 2. NOTE: All acoustically balanced physical spaces require a blend of absorption, diffusion, and low-end management for professional results. Please see the ‘How Many?’ tab for suggested ordering quantities.
Frequency Range: 60 to 500Hz with corner placement
Material: USAP - Unique Sonitus Acoustic Polyester- fire resistant FMVSS 302 <100mm/min
Size: 23.6” x 23.6” x 9.7” (60cm x60cm x 25cm)
Coverage Area: 3.9 sq. ft.
Weight: 6 lbs.
Master Pack: 2 Units
Mounting: Construction Adhesive or optional SMMS kit (4 magnets)
Colors: White
Special OrderColors: Black, Wine Red, Walnut, Mahogany, Poplar (light maple)
• 100-200 sq. ft. = 2 Units
• 201-300 sq. ft. = 4 Units
• 301-400 sq. ft. = 6 Units
• 401-500 sq. ft. = 8 Units
• 501-600 sq. ft. = 12 Units
• 601-700 sq. ft. = 16 Units
For those who don`t have a fancy pants Shure Beta 91A boundary microphone but would like to place their traditional microphone inside the bass drum or use 2 mics. The Kicker mic stand is a simple fixed-height stand that perfectly fits into the sculpted channel in the Kicker All In One and Kicker 2.0. The stand is universal for all kinds of bass drum microphones and comes with a 5/8" male to 3/8" female microphone thread adapter. Velcro for stay-put positioning is included.
Kicker 4.0 provides a tight, powerful kick drum sound by damping both your front and rear drum heads. Kicker 4.0 saves you time in the studio and on stage by quickly getting you to that perfect kick tone.
Kicker 4.0 reveals your bass drum’s attack and soaks up those muddy and annoying mid-frequencies. Its magic comes from a top-secret formulation of polyester foam and its uniquely engineered design. The result is sonic consistency and dynamics. Your low-cost bass drum will sound amazing, and your expensive drum will finally deliver on its promise.
Kicker 4.0 allows you to tune the damping via three removable foam tubes. It also features a cool way to place a Shure Beta 91A microphone inside your kick drum. Use any traditional mic by adding the optional Kicker Mic Stand. You get a powerful, focused sound with little or no mic EQ, saving you hours in the studio and in sound checks.
Using a trigger to playback samples from your kick? Kicker 4.0 increases your trigger accuracy while reducing false triggering due to bleed from other drums, rattles and amps.
Sizes (Diameter x Depth):
18 "x 14"
20" x 10"
20" x 14"
20" x 15"
20" x 16"
20" x 17"
20" x 17.5"
20" x 20"
22" x 14"
22" x 17"
22" x 17.5"
22" x 18"
22" x 20"
24" x 14"
24" x 16"
24" x 17"
24" x 17.5"
24" x 18"
26" x 14"
26" x 16"
The SMMS system allows you to mount panels that can be removed or re-positioned later fairly easy. One kit contains 24 magnets, 6 spacers, and 24 washers which is enough to mount 6 panels (4 each). The washers get screwed to the walls (you provide appropriate screws for your wall type), the magnets get hot glued to the acoustical components. Do not use with the Bigfusor II Solid, 6-Strip and Cloud Acoustical Absorber Panels- they all come with their own mounting systems.
One kit contains 24 magnets and 24 washers which is enough to mount 6 panels (4 each).
Detailed Instruction Video: https://www.youtube.com/watch?v=iytjPR5oV0I
IMPORTANT: Don't use the magnetic mounting system for these products:
Use the SMMS magnetic mounting systems to mounting the follow components:
Do not use the SMMS magnetic mounting system for these products:
Systems Requirements (Home Cinema):
Standard:
100-200 sq.ft. -- 5 kits
201-300 sq.ft. -- 5 kits
301-400 sq.ft. -- 7 kits
401-500 sq.ft. -- 8 kits
501-600 sq.ft. -- 9 kits
601-750 sq.ft. -- 11 kits
Premium:
100-200 sq.ft. -- 5 kits
201-300 sq.ft. -- 7 kits
301-400 sq.ft. -- 7 kits
401-500 sq.ft. -- 8 kits
501-600 sq.ft. -- 9 kits
601-750 sq.ft. -- 11 kits
Ultra:
100-200 sq.ft. -- 2 kits
201-300 sq.ft. -- 3 kits
301-400 sq.ft. -- 3 kits
401-500 sq.ft. -- 4 kits
501-600 sq.ft. -- 4 kits
601-750 sq.ft. -- 4 kits
Systems Requirements (Studio):
Standard:
100-200 sq.ft. -- 5 kits
201-300 sq.ft. -- 5 kits
301-400 sq.ft. -- 7 kits
401-500 sq.ft. -- 8 kits
Premium:
100-200 sq.ft. -- 5 kits
201-300 sq.ft. -- 7 kits
301-400 sq.ft. -- 7 kits
401-500 sq.ft. -- 8 kits
Ultra:
100-200 sq.ft. -- 2 kits
201-300 sq.ft. -- 3 kits
301-400 sq.ft. -- 3 kits
401-500 sq.ft. -- 4 kits
Contains over 80 test signals, laid out in a logical progression for quick calibration and debugging of 5.1 channel systems with THX Surround EX. Contains: Midrange Pink Noise Wideband Pink Noise LF Pink Noise 1/2 Point Check Signals Imaging Tests 1/3 Octave Pink Noise 1 Octave Pink Noise 1/3 Octave Burst Headroom Test Noise Leakage Tests Sinewave Signals Swept Sinewave Signals 5.1 Channel Music and "A Whole Lotta Bass"
